| Model Number |
500 |
630 |
|
Dia. Of Single Wire(mm)
|
Copper |
1.5-5.0 |
| Aluminum |
1.8-5.0 |
| Max.Section Square(mm2) |
Cu |
500 |
| Al |
630 |
| Max Linear Speed(m/min) |
7.32-55.29 |
7.62-57.93 |
| Pay-off In Cage |
PND500 |
| Stranding Pitch(mm) |
45-1105 |
56-1259 |
| Take-up Bobbins(mm) |
PN1600-PN2500 |
| Capstan(mm) |
2000mm |
Features
1.All Cages, Pre-Spiraling Heads, Taping Head, Capstan & Takeup are separately driven.
2.All bobbins can be loaded/unloaded simultaneously by automatic loading equipment, thereby reducing loading/unloading time to Max. 30 minutes.
3.Lay is fed in MMI (Operator touch screen) instead of Gearbox. Any lay value in the range can be set & achieved that ensure easy operation.
4.In Power failure situation, the machine comes to a controlled stop by emergency braking system, enabling the bobbin is held by spring pressure with a secondary positive lock. The release of bobbin is by externally plugged pneumatic compressed Air.
5.Constant Bobbin back tension achieved by Electronic pneumatic valve & Single bobbin rotation is electronically sensed for maintaining consistent tension by positive motor control system or passive mechanical equipment.
6.Multiple bobbin size available(400,500,630.etc)
7.Mutiple host with mutiple cage number((6.12.18.24.30)) optional
| FAQ |
|
1,Q: What is your main brand for the electrical and mechanical parts?
A: China famous brand
|
|
2, Q:could we appoint the parts brand?
A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like.
|
|
3, Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge
|
|
4, Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge
|
|
5, Q: could you do the design for the whole plant
A: Yes , we can.
|
|
6, Q: could you offer the production process design
A: Yes , we can.
|
|
7, Q: what is the difference with other supplier?
A: what we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control and education and assist machine and raw material offering .
|
|
8.Q:What's the payment terms?
A:T/T,30% deposit and 70% balance before delivery.
|
|
9, Q:How long the guarantee:
A: one year and charge for repair the whole life.
|
